Centerline Deep Drilling Machines for Cylindrical Workpieces

A SERIES OF CUSTOM-TAILORED MACHINES

IMSA “MFT” and “MFTB” deep hole drilling machines are dedicated to cylindrical parts such as transmission housings, cam shafts, gear shafts, injectors, lubricators, couplings, valves, drive valves… in general, to solids of revolution with a centered deep drilling along their axis.

These deep hole drilling machines are customized for drilling depth, diameters, number of spindles; our range starts from machines for small lots to high-productivity lines. We also propose different solutions for automated load, as a completion to the supply.

TWO DRILLING METHODS

IMSA machined for centerline drilling in shafts use two different drilling methods depending on the diameters:

  • deep hole drilling by “gun drill” tool for our MFT Series
  • deep hole drilling by “BTA/STS” tool for our MFTB Series

Learn more: The Deep Drilling Process

Centerline Deep Drilling Machines for Cylindrical Workpieces

MFT 1000EVO

Centerline deep hole drilling machine. Single spindle. Drilling method: gun drill tool. Workpiece in counter-rotation. Drilling diameters: 4 – 25 mm. Drilling depth (160 x Ø) max. 1000 mm. This EVO version manages pressure and flow by an inverter; moreover, it enables a very quick setup thanks to full-cnc movements.

MFT 500CR – MFT 1000CR – MFT 1500CR

Centerline deep hole drilling machines. Single spindle. Drilling method: gun drill tool. Workpiece in counter-rotation. Drilling diameters: (4) 6 – 25 mm. Drilling depth max.: as per machine name, respectively 500 mm, 1000 mm, 1500 mm.

MFT 750/2T CR – MFT 1500/2T CR

Centerline deep hole drilling machines. These “2T” machines are equipped with a single carriage with two spindles, enabling you to drill 2 identical parts in each drilling cycle. Method: gun drilling. Workpiece in counter-rotation. Drilling diameters: 6 – 24 mm. Drilling depth (respectively) 750 mm, 1500 mm.

MFT 1000 /2Ti CR – MFT 1500 /2Ti CR

Centerline deep hole drilling machines. These “2Ti” machines are equipped with 2 independent drilling carriages that enable you to drill 2 different workpieces in each cycle. Method: gun drilling. Workpiece in counter-rotation. Drilling diameters: 6 – 25 mm. Drilling depth (respectively) 1000 mm, 1500 mm.

MFT 750 /6 CR

Small diameter centerline deep drilling machine for cylindrical parts, especially for the medical industry. Single spindle. Method: by gun drill tool. Workpiece in counter-rotation. Drilling diameters: 1,5 – 6 mm. Drilling depth: max. 120mm approx. for Ø 1,5 – 3 mm; max. 750 mm for Ø 3 – 6 mm.

MFT750/12CR macchina foratrice fori profondi IMSA

MFT 750 /12 CR

Centerline deep hole drilling machine for cylindrical parts, especially for the medical industry. Single spindle. Method: by gun drill tool. Workpiece in counter-rotation. Drilling diameter range: 3 – 12 mm. Dilling depth: (160 x Ø) max. 750 mm.

IMSA gun drilling machine for cylindrical parts MFT1500/32CR - workpiece and steadyrest

MFT 1000 /32 CR – MFT 1500 /32 CR

Centerline deep hole drilling machines for steel shaft and other cylindrical parts that have to be drilled on their rotation axis until Ø32, such as: gear shafts, aerospace industry, flanges for industrial applications. Single spindle. Method: gun drilling. Drilling diameters: 6 – 32 mm. Drilling depth (respectively) 1000 mm, 1500 mm.

IMSA - Centerline deep drilling machine MFT1000/43CR

MFT 1000 /43CR – MFT 1500 /43CR

Centerline deep hole drilling machines for steel shaft and other cylindrical parts that have to be drilled on their rotation axis until Ø43, such as: gear shafts, aerospace industry, flanges for industrial applications. Single spindle. Method: gun drilling. Drilling diameters: 8 – 43 mm. Drilling depth (respectively) 1000 mm, 1500 mm.

MFTB1000/51 GDK – MFTB1500/51 GDK – MFTB2000/51 GDK

Centerline deep hole drilling machine for cylindrical parts. In the intermediate diameter range between the Gun Drilling and the BTA Drilling, we propose a Double-Setup flexible solution we called IMSA “GDK” System. This enables you to better take advantage of both tool types. Drilling diameter range with gun drill tools: 8 -24 mm; drilling diameter range with BTA tools: 18 – 51 mm.

Cnc Deep Hole Drilling Machine for cylindrical parts, on-center holes, by gundrill and BTA tools

MFTB 1000/76 GDK – MFTB 2000 /76 GDK – MFTB 3000 /76 GDK

Centerline deep hole drilling machine for cylindrical parts. In the intermediate diameter range between the Gun Drilling and the BTA Drilling, we propose a Double-Setup flexible solution we called IMSA “GDK” System. This enables you to better take advantage of both tool types. Drilling diameter range with gun drill tools: 8 -25 mm solid; drilling diameter range with BTA tools: 20 – 76 mm solid.

MFTB1000/110 – MFTB2000/110

Centerline deep hole drilling machine for steel shafts and other cylindrical parts that have to be drilled on their rotation axis. Deep drilling method: BTA/STS. Drilling depth (respectively) 1000 mm, 2000 mm. Drilling diameter range: 20 – 110 mm (in option, up to 135 mm in counter-boring).

IMSA BTA deep hole drilling machine

MFTB 3300 /110EVO

Centerline deep hole drilling machine specific for aeronautical shafts, martensitic stainless steels in particular. Single spindle. Drilling method: by BTA tools. Workpiece in counter-rotation. Drilling diameters: 30 – 110 mm. Drilling depth: max. 3300 mm.

MFTB2000 /200

Centerline deep hole drilling machine for steel shafts and other cylindrical parts that have to be drilled on their rotation axis. Deep drilling method: BTA/STS. Drilling depth: 2000 mm. Drilling diameter range: 50 -200 mm.
