PRE-OWNED IMSA MACHINE FULLY REVAMPED AND RE-REGISTERED BY THE MANUFACTURER
CNC deep hole drilling machine for hole Ø 4-20 mm solid, by gun drill tool, max. depth 1000 mm.
Infinite position cnc-rotary table, size 800 x 1000 mm, load 4000 kg.
Column horizontal movement 1000 mm.
Headstock vertical movement 930 mm.
SEPARATE spindles for gun drilling and auxiliary tapping/milling:
- deep drilling spindle 5,5 kW, 4200 rpm; movable steady rests with IMSAUTOFOCUS system, chip box with quick change of front nose bushing;
- milling spindle with automatic booster tie-rod for ISO40 tools, located on the same headstock but on separate axis of the deep drilling spindle. Automatic switchover gundrilling/milling and back.
Chip conveyor. Recovery, filtration and cooling system for the deep drilling oil.
CNC Heidenhain TNC620 with specific gun drilling functions, ready to be integrated in LAN, card for remote assistance.
